EVO II Dual 8K Thermal Drone

$9,998.00

  • FLIR Thermal + 8K Visible Sensor
  • Picture in Picture (PiP) Mode
  • 40 Minute Max Flight Time
  • 5.5 Mile Control Range

Call for availability

Category: Tag:

Description

The Autel EVO II Dual is Autel’s commercial/enterprise platform within the EVO II series that features a FLIR Boson 640 thermal sensor along with an 8K/20MP visual sensor. These two sensors are housed in one 3-axis gimbal-stabilized camera unit. Maximum flight time on the EVO II Dual is 40 minutes in forward flight, while you can expect about 35 minutes in hover flight.

FLIR Thermal + 8K Visible Sensor
Collect two image sets at once with the use of both thermal and visible imagery.

Picture in Picture (PiP) Mode
Overlay both your thermal and visible light data in one image with more detail.

40 Minute Max Flight Time
Standard 7100 mAh rechargeable battery. Up to 35 minutes at a hover.

5.5 Mile Control Range
Not all users will ever need to travel this far, but a longer range means a strong signal.

Autel EVO II Dual Specs:

Aircraft

Takeoff Weight2.62 lbs (1192 g)
DimensionsFolded: 8.98 x 5.24 x 4.33 in (L x W x H)
(228 x 133 x 110 mm)
Unfolded: 16.69 x 13.94 x 4.33 in (L x W x H)
(424 x 354 x 110 mm)
Diagonal Distance15.63 in (397 mm)
Max Ascent SpeedStandard mode: 11.18 mph (5 m/s)
Ludicrous mode: 17.89 mph (8 m/s)
Max Descent SpeedStandard mode: 6.71 mph (3 m/s)
Ludicrous mode: 8.94 mph (4 m/s)
Max Speed (near sea level, no wind)Standard mode: 33.55 mph (15 m/s)
Ludicrous mode: 44.73 mph (20 m/s)
Max Service Ceiling Above Sea Level22,965 ft (7000 m)
Max Flight Time (no wind)40 minutes
Max Hovering Time (no wind)35 minutes
Max Flight Distance (no wind)15.53 miles (25 km)
Max Wind Speed Resistance39-46 mph (Level 8)
Max Tilt AngleStandard mode: 28°
Ludicrous mode: 33°
Max Angular Velocity120°/second
Operating Temperature Range14°F to 104°F (-10°C to 40°C)
Operating Frequency2.4~2.4835GHz
Transmission Power (EIRP)2.4~2.4835GHz
FCC: ≤26 dBm
ISED: ≤26 dBm
CE: ≤20 dBm
RCM: ≤20 dBm
SRRC: ≤26 dBm
GNSSGPS/GLONASS/VIO/ATTI
Hovering Accuracy RangeVertical:
± 0.78 in (when vision positioning is active)
± 7.87 in (with GPS positioning)
Horizontal:
± 0.78 in (when vision positioning is active)
± 3.28 ft (with GPS positioning)
Internal Storage8 GB
SD StorageStandard: 32 GB
Max Micro SD Card Supported: 256 GB

Camera

Sensor1/2″ CMOS 48 MP + FLIR LWIR Sensor 640×512
LensInfrared Camera: FOV 32°, 14mm Lens
ISO RangeVisible Light & Picture in Picture (PiP) Mode: IOS100~3200 (Auto) 100-3200 (Manual)
Infrared: N/A
Shutter SpeedVisible Light & Picture in Picture (PiP) Mode: 8 ~ 1/8000s
Digital Zoom1 ~ 8x (Max. 4x lossless zoom of Visible Light mode)
Still Image ResolutionVisible Light:
8000×6000 (4:3)
7680×4320 (16:9)
4000×3000 (4:3)
3840×2160 (16:9)Infrared Mode:
640x512Picture in Picture Mode: 1920×1080, 1280×720
Still Image FormatVisible Light: JPEG / DNG / JPEG+DNG
Infrared & Picture in Picture mode: JPEG
Still Photography ModesVisible Light:
Single Shot
Burst Shooting: 3/5 framesInfrared & Picture in Picture mode: Single shot, Burst shooting, Time
Video ResolutionVisible Light:
7680×4320 p25/p24
5760×3240 p30/p25/p24
3840×2160 p60/p50/p48/p30/p25/p24
2720×1528 p120/p60/p50/p48/p30/p25/p24
1920×1080 p120/p60/p50/p48/p30/p25/p24Infrared Mode: 640×512 (US)Picture in Picture Mode: 1920×1080 p30, 1280×720 p30
Video FormatMOV / MP4
CodecsH.264 / H.265
Max Video Bitrate120Mbps
HDR Video RecordingVisible Light Mode: Supports 3840×2160, 2720×1528, 1920×1080 HDR video recording

Gimbal

Weight4.76 oz (135 grams)
Mechanical RangePitch: -135~45°
Roll: -45~45°
Yaw: ±100°
Controllable RangePitch: -90~0°
Yaw: -90~90°
Stabilization3-Axis (Tilt, Roll, Pan)
Max Control Speed (Tilt)200°/s
Angular Vibration Range±0.003° @ 10m/s
±0.008° @ 15m/s
±0.013° @ 20m/s

Sensing System (Obstacle Avoidance)

Sensing SystemOmnidirectional Obstacle Sensing
ForwardPrecision Measurement Range: 0.5-20 m
Detectable Range: 0.5-40m
Effective Sensing Speed: <15m/s
FOV: Horizontal: 60°, Vertical: 80°
BackwardPrecision Measurement Range: 0.5-16 m
Detectable Range: 0.5-32m
Effective Sensing Speed: <12m/s
FOV: Horizontal: 60°, Vertical: 80°
UpwardPrecision Measurement Range: 0.5-12 m
Detectable Range: 0.5-24m
Effective Sensing Speed: <6m/s
FOV: Horizontal: 60°, Vertical: 50°
DownwardPrecision Measurement Range: 0.5-11 m
Detectable Range: 0.5-22m
Effective Sensing Speed: <6m/s
FOV: Horizontal: 90°, Vertical: 70°
SidesPrecision Measurement Range: 0.5-12 m
Detectable Range: 0.5-24m
Effective Sensing Speed: <10m/s
FOV: Horizontal: 60°, Vertical: 50°
Operating EnvironmentForward, Backward, Upward and Sides: Surface with clear pattern and adequate lighting (lux > 20)
Downward: Surface with clear pattern and adequate lighting (lux > 20)
Detects diffuse reflective surfaces (>20%) (walls, trees, people, etc.)

Remote Controller

Operating Frequency2.4~2.4835GHz
Max Transmission Distance (unobstructed, free of interferenceFCC: 5.59 miles (9 km)
CE: 3.10 miles (5 km)
Operating Temperature Range14°F to 104°F (-10°C to 40°C)
Transmission Power (EIRP)2.4~2.4835GHz
FCC: ≤26 dBm
ISED: ≤26 dBm
CE: ≤20 dBm
RCM: ≤20 dBm
SRRC: ≤26 dBm
Battery5000 mAh
Weight370 grams (13.05 ounces)
Operating Current/Voltage1.7A @ 3.7V
Charging Temperature Range32°F to 104°F (0 to 40°C)
Supported Mobile Device SizeMax Length: 3.30″ (84mm)
Max Thickness: 0.51″ (13mm)
Supported USB Port TypesLightning, Micro USB (Type-B), USB-C
Operating Hours3 hours
OLED Brightness330 nit

Battery

Capacity7100 mAh
Voltage11.55 V
Max Charging Voltage13.2 V
Battery TypeLiPo 3S
Energy82 Wh
Net Weight365 grams (12.87 ounces)
Charging Temperature Range41°F to 104°F (5°C to 40°C)
Max Charging Power82 W

What’s Included?

(1) Aircraft
(1) Remote Controller
(3) Flight Batteries
(1) Battery Charging Hub
(1) 110V Wall Charger
(1) 12V Car Charger
(3) Propellers (pairs)
(1) EVO II Hard Rugged Case
(1) 12″ Cable USB Micro A – USB Type C
(1) 12″ Cable USB Micro A – USB Micro B
(1) Gimbal Cover
(1) EVO II FoxFury Lighting Kit (including 1 saddle and 2 lights)
(1) 32GB U3 SD Card
(1) Limited 1-Year Autel Warranty
